Manufacturer
Manufacturer: XFX
Model Number:RX-65XT4DBDQ
Product Name: AMD Radeon™ RX 6500 XT
Product Description: XFX SPEEDSTER QICK210 RADEON RX 6500 XT BLACK Gaming Graphics Card with 4GB GDDR6 HDMI , AMD RDNA™ 2
Short Description : XFX Speedster QICK210 Radeon RX 6500 XT Black Edition 4GB
Launch Date: 19 Jan, 2022
UPC Number: 840191500152
Specifications
Bus Type: PCI-E 4.0
Clock Speeds:
Base clock Up to: 2420MHz
Game Clock Up To: 2685MHz*
Boost clock Up to: 2825 MHz**
Stream Processors: 1024
Compute Units: 16
Memory Bus: 64 bit
Memory Clock: 18 Gbps
Memory Size: 4 GB
Memory Type: GDDR6
Card Profile: Dual Slot
Thermal Solution: Dual Fan
*"Game Clock" is the expected GPU clock when running in typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
**"Boost Clock" is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
Outputs
DisplayPort: 1.4 with DSC
HDMI™: 2.1 VRR and FRL
Output : Display Port 1
Output: HDMI 1
Requirements
External Power: 1x PCI-E 6 pin connections
Minimum Power Supply Requirement: 400 watt
XFX Recommended Power Supply: 500 watt
Certifications
RoHS
Package Contents
Installation Guide: 1
Estimated Dimensions & Weights
Card Dimension (cm): 23.3 x 13 x 4.2
Card Dimension (inch): 9.17 x 5.12 x 1.65
Master Carton Dimensions (cm): 62 x 41 x 39
Master Carton Dimensions (inch): 24.41 x 16.14 x 15.35
Master Carton Weight (Kg): 10kg
Master Carton Weight (lb): 22.05lb
Package Dimensions (cm): 36.5 x 19.4 x 11.6
Package Dimensions (inch): 14.21 x 7.64 x 4.57
Package Weight (Kg): 1kg
Package Weight (lb): 2.2lb
Units/Carton: 10
Technologies
AMD RDNA™ 2 Architecture
DirectX® 12 Ultimate
Hardware Raytracing
FidelityFX
Radeon Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
6nm Technology
GDDR6 Memory
PCI® Express 4.0 Support
AMD FreeSync™ Technology*
DisplayPort™ 1.4 with DSC
HDMI™ 2.1 VRR
Video Streaming up to 8K
AMD FidelityFX*
Radeon™ Image Sharpening*
Radeon™ Anti-Lag*
Radeon™ Software
Game Driver Optimizations
OpenGL 4.5 Support
OpenCL Support
* Not compatible with Windows 7. For more information on Radeon technologies, visit: AMD.com/gamingdetails
Key Features
Advanced 6nm GPU
PCI Express 4.0 Support
Radeon Image Sharpening
FidelityFX
Radeon Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
6nm Technology
AMD Virtual Super Resolution (VSR)
AMD Relive
AMD FreeSync 2 HDR
AMD Frame Rate Target Control (FRTC)
AMD Eyefinity multi-display technology
AMD Radeon Adrenalin Software
AMD WattMan
HDMI 2.0b
Displayport 1.4 w/ DSC
Dolby TrueHD and DTS-HD Master Audio Support
OpenGL 4.5 Support
OpenCL Support
Downloads
FEATURES
BUILT FOR THE GAMER
PERFORMANCE TO STEP OF YOUR GAME
Impressive 1080p gaming performance and boosted frame rates with AMD FidelityFX™ Super Resolution technology.
AIRFLOW AND AESTHETICS
Finding the balance between a good looking card and maximizing it's performance is an art. Where we could improve airflow, we did it, we opened it up while keeping the design clean and cool.
AMD SMART ACCESS MEMORY
Get more performance through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCI Express.
XFX ZERO DB AUTO LOAD SENSING FANS
XFX Fans are equipped to run at the highest possible performance, while our Zero DB fan system will also keep your fans running at efficient RPM in order to minimize annoying fan noise by lowering RPM all the way down to Zero RPM. When the heat is on during intense gaming, our fans will speed up as needed.
AMD INFINITY CACHE
High-performance bandwidth. AMD Infinity Cache enables high bandwidth performance at low power, and low latency when gaming.
VIVID VISUALS
With immersive gaming technologies and support for DirectX® 12 Ultimate, AMD Radeon™ RX 6500 XT graphics cards draw you into the action. Experience gaming with realistic lighting, shadows, and reflections along with rich detail, thanks to DirectX® Raytracing (DXR), variable rate shading (VRS), and AMD FidelityFX™ technology features, optimized for AMD RDNA™ 2 architecture.
ULTRA HD SUPPORT
The XFX RX 6500 XT is built to deliver serious 1080p gaming and impressive frame rates. . With support for 8k you are ready for Next-Gen displays. See everything in mind blowing detail without sacrificing performance.
REAL TIME RAY TRACING
AMD Radeon™ RX 6000 Series graphics cards with enhanced RDNA 2 compute units featuring Ray Accelerators are optimized to deliver real-time lighting, shadow, and reflection realism with DirectX Raytracing, the new standard for next generation gaming visuals to increase visual quality in gaming.
GET A BOOST IN FRAMES FOR YOUR GAMES
AMD FidelityFX Super Resolution (FSR) boosts your frame rates 2.4X on average in FSR supported games with high-quality, high-resolution gaming experiences delivered by AMD Radeon™ RX 6000 Series graphics cards. Optimize your gaming experience between four presets, ranging from best visual fidelity to maximum performance. Visit https://www.amd.com/en/technologies/radeon-software-fidelityfx-super-resolution/ for more information.
