Manufacturer
Manufacturer: XFX
Model Number:RX-66XT8TBDQ
Product Name: AMD Radeon™ RX 6600 XT
Product Description: XFX SPEEDSTER MERC308 RADEON RX 6600 XT BLACK Gaming Graphics Card with 8GB GDDR6 HDMI 3xDP, AMD RDNA™ 2
Short Description : XFX SPEEDSTER MERC308 RADEON RX 6600 XT BLACK Gaming Graphics Card
Launch Date: 11 Aug,2021
UPC Number: 778656081512
Specifications
Bus Type: PCI-E 4.0 @ 8x
Clock Speeds:
Base clock Up to: 2064 MHz
Game Clock Up To: 2428 MHz*
Boost clock Up to: 2607 MHz**
Stream Processors: 2048
Compute Units: 32
Memory Bus: 128 bit
Memory Clock: 16 Gbps
Memory Size: 8 GB
Memory Type: GDDR6
Card Profile: 2.5 Slot
Thermal Solution: Triple Fan
*"Game Clock" is the expected GPU clock when running in typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
**"Boost Clock" is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
Outputs
DisplayPort: 1.4 with DSC
HDMI™: 2.1 VRR and FRL
Output : Display Port 3
Output: HDMI 1
Requirements
External Power: 1x PCI-E 8 pin connections
Minimum Power Supply Requirement: 650 watt
XFX Recommended Power Supply: XFX 750W PSU
Certifications
RoHS
Package Contents
Installation Guide: 1
Estimated Dimensions & Weights
Card Dimension (cm): 27.4 x 11.4 x 5
Card Dimension (inch): 10.79 x 4.49 x 1.97
Master Carton Dimensions (cm): 62 x 41 x 39
Master Carton Dimensions (inch): 24.41 x 16.14 x 15.35
Master Carton Weight (Kg): TBC
Master Carton Weight (lb): TBC
Package Dimensions (cm): 36.5 x 19.8 x 12
Package Dimensions (inch): 14.37 x 7.80 x 4.72
Package Weight (Kg): TBC
Package Weight (lb): TBC
Units/Carton: 10
Technologies
AMD RDNA™ 2 Architecture
DirectX® 12 Ultimate
Hardware Raytracing
FidelityFX
Radeon Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
7nm Technology
GDDR6 Memory
PCI® Express 4.0 Support
AMD FreeSync™ Technology*
DisplayPort™ 1.4 with DSC
HDMI™ 2.1 VRR
Video Streaming up to 8K
AMD FidelityFX*
Radeon™ Image Sharpening*
Radeon™ Anti-Lag*
Radeon™ Software
Game Driver Optimizations
OpenGL 4.5 Support
OpenCL Support
* Not compatible with Windows 7. For more information on Radeon technologies, visit: AMD.com/gamingdetails
Key Features
Advanced 7nm GPU
PCI Express 4.0 Support
Radeon Image Sharpening
FidelityFX
Radeon Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
7nm Technology
AMD Virtual Super Resolution (VSR)
AMD Relive
AMD FreeSync 2 HDR
AMD Frame Rate Target Control (FRTC)
AMD Eyefinity multi-display technology
AMD Radeon Adrenalin Software
AMD WattMan
HDMI 2.0b
Displayport 1.4 w/ DSC
Dolby TrueHD and DTS-HD Master Audio Support
Up to 5 displays supported, (may require the use of MST Hubs)
OpenGL 4.5 Support
OpenCL Support
Downloads
FEATURES
BUILT FOR THE GAMER
POWERHOUSE PERFORMANCE FOR 1080P
AMD Radeon™ RX 6600 XT graphics cards deliver serious 1080p gaming and ultra-high frame rates. Get up to 32 high-performance compute units, groundbreaking AMD Infinity Cache, and up to 8GB of dedicated GDDR6 memory. Experience the next gen of gaming performance with AMD Smart Access Memory technology when you pair an AMD Radeon™ RX 6600 XT graphics card with an AMD Ryzen™ 5000 Series desktop processor.
AIRFLOW AND AESTHETICS
Finding the balance between a good looking card and maximizing it's performance is an art. Where we could improve airflow, we did it, we opened it up while keeping the design clean and cool.
XFX GHOST THERMAL AND COOLING TECHNOLOGIES
XFX's all new Ghost Thermal design cools your GPU better than ever before. Our new design features a straight through airflow venting to significantly improves cooling and compliments open design of the Ghost Thermal floating shroud design. Our 9 blade fans increase total air flow and provides long lasting quieter operation.
XFX DUAL BIOS READY
We know enthusiast like options, so for our MERC 308 RX 6600 series graphics cards we are offering dual BIOS. Giving a backup BIOS in the case of a failed BIOS update.
AMD SMART ACCESS MEMORY
Get more performance through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCI Express.
XFX ZERO DB AUTO LOAD SENSING FANS
XFX Fans are equipped to run at the highest possible performance, while our Zero DB fan system will also keep your fans running at efficient RPM in order to minimize annoying fan noise by lowering RPM all the way down to Zero RPM. When the heat is on during intense gaming, our fans will speed up as needed.
AMD INFINITY CACHE
High-performance bandwidth. AMD Infinity Cache enables high bandwidth performance at low power, and low latency when gaming.
VIVID VISUALS
Experience a new level of immersion with the Radeon™ RX 6000 Series graphics cards with support for the latest software innovations such as DirectX® 12 Ultimate and the latest AMD FidelityFX™ technology feature set, enabling realistic lighting, shadows, and reflections in extreme detail. AMD FidelityFX™ technology features are optimized for the AMD RDNA™ 2 architecture to power the next generation of gaming visuals at high framerates, providing a mesmerizing gaming experience.
ULTRA HD SUPPORT
The XFX RX 6600 XT is built for high-performance high definition gameplay. Experience smooth gameplay performance at 1080p.With support for 8k you are ready for Next-Gen displays. See everything in mind blowing detail without sacrificing performance.
REAL TIME RAY TRACING
AMD Radeon RX 6000 Series graphics cards with enhanced RDNA 2 compute units featuring Ray Accelerators are optimized to deliver real-time lighting, shadow, and reflection realism with DirectX Raytracing, the new standard for next generation gaming visuals to increase visual quality in gaming.
GET A BOOST IN FRAMES FOR YOUR GAMES
AMD FidelityFX Super Resolution (FSR) boosts your frame rates 2.4X on average in FSR supported games with high-quality, high-resolution gaming experiences delivered by AMD Radeon RX 6000 Series graphics cards. Optimize your gaming experience between four presets, ranging from best visual fidelity to maximum performance. Visit https://www.amd.com/en/technologies/radeon-software-fidelityfx-super-resolution/ for more information.
